Edgenius OPC UA Server
Share Operational Data
Contact Us Learn more about ABB Ability™ Edgenius
Share operational data smoothly with third-party systems
The OPC UA Server application enables third party on-premise systems to access data on the edge using OPC UA. Typical use cases can be an external HMI system for data visualization or an external historian storing data from the edge. Once downloaded to the edge, the OPC UA Server application exposes the entire information model on the edge as the OPC UA Server namespace. A client can subscribe to all available variables. The OPC UA Server supports OPC UA Data Access version 1.04, including OPC UA X.509 certificate for client and server authentication. An external OPC UA client can access all variables in the namespace post authentication.
Benefits
Edgenius OPC UA Server enables external on-premise systems to access data on the edge. OPC UA Server application exposes the entire information model on the edge as the OPC UA Server namespace from which a client can subscribe for all available variables.
The OPC UA Server supports OPC UA Data Access version 1.04, including OPC UA X.509 certificate for client and server authentication.
Typical use cases can be an external HMI system for data visualization from the edge or an external historian storing data from the edge.
Edition & Pricing
All editions
Included
  • ABB Information Model context
Excluded
  • Hardware
Edgenius OPC UA Server
  • Tier 1: Up to 200 var/min
  • Tier 2: Up to 500 var/min
  • Tier 3: Up to 1000 var/min
  • Tier 4: Up to 2500 var/min
  • Tier 5: Up to 5000 var/min

Prerequisites: Valid Edgenius Connect or Connect & Compute subscription

Features
Services
Discovery Services

This set of services defines the services that discover the Endpoints implemented by a Server and read the security configuration for those Endpoints. The Discovery Services are implemented by individual Servers and by dedicated Discovery Servers. OPC 10000-12 describes how to use the Discovery Services with dedicated Discovery Servers.

Subscription services

Services that clients can use to identify the kind of data is available for notifications. Clients can decide how much and when they wish to get notified about changes, not only to data values but to the meta-data and structure of Objects.

Node Services

Services that clients can use to create, delete and modify the data structure maintained by the Server.
